| Order Number | Expanded | Recovered | Lengths | |||||
| Internal Diameter (Min) D |
Internal Diameter (Max) D |
Wall Thickness (Nom) W |
||||||
| mm | in | mm | in | mm | in | m | ft | |
| 0047 | 1.2 | 3/64 | 0.6 | 3/128 | 0.45 | 0.018 | 300 | 1,000 |
| 0062 | 1.6 | 1/16 | 0.8 | 1/32 | 0.45 | 0.018 | 300 | 1,000 |
| 0093 | 2.4 | 3/32 | 1.2 | 3/64 | 0.51 | 0.020 | 300 | 1,000 |
| 0125 | 3.2 | 1/8 | 1.6 | 1/16 | 0.51 | 0.020 | 300 | 1,000 |
| 0187 | 4.8 | 3/16 | 2.4 | 3/32 | 0.51 | 0.020 | 300 | 1,000 |
| 0250 | 6.4 | 1/4 | 3.2 | 1/8 | 0.64 | 0.025 | 150 | 500 |
| 0375 | 9.5 | 3/8 | 4.8 | 3/16 | 0.64 | 0.025 | 150 | 500 |
| 0500 | 12.7 | 1/2 | 6.4 | 1/4 | 0.64 | 0.025 | 60 | 200 |
| 0625 | 16.0 | 5/8 | 8.0 | 5/16 | 0.64 | 0.030 | 60 | 200 |
| 0750 | 19.0 | 3/4 | 9.5 | 3/8 | 0.76 | 0.030 | 30 | 100 |
| 1000 | 25.4 | 1 | 12.7 | 1/2 | 0.89 | 0.035 | 30 | 100 |
| 1250 | 32.0 | 1 ¼ | 16.0 | 5/8 | 0.89 | 0.040 | 30 | 100 |
| 1500 | 38.1 | 1 ½ | 19.0 | 3/4 | 1.02 | 0.040 | 30 | 100 |
| 2000 | 50.8 | 2 | 25.4 | 1 | 1.14 | 0.060 | 30 | 100 |
| 3000 | 76.2 | 3 | 38.1 | 1 ½ | 1.27 | 0.060 | 15 | 50 |
| 4000 | 101.6 | 4 | 50.8 | 2 | 1.40 | 0.060 | 15 | 50 |
